CS series – container-transportable post-screens
A post screen for every crusher. Each size of screen in the CS series is designed to be perfectly compatible with our mobile crushers. All the screens are powerful and process grain from recycling and natural rock as well as round grain to standardised grain sizes.
Depending on the type of screen and crusher, between two and four fractions can be produced in a single pass. Like all RM products, the post screens in the CS series stand out thanks to their low maintenance requirement and useful features, such as self-cleaning screen decks.
|
RM CS post-screens range |
RM CS2500 1D/2D |
RM CS3600 2D RM |
RM CS4800 2D |
|
Output |
up to 80 t/h (100 t/h), depending on screen angle, mesh size and feed material |
up to 150 t/h, depending on screen angle, mesh size and feed material |
up to 250 t/h, depending on screen angle, mesh size and feed material |
|
Transport system |
by hook-lift |
by hook-lift |
by hook-lift |
|
Transport weight |
4 t (4,7 t) |
6.3 t |
7 t |
|
Deck data |
1 deck (2 deck) |
2 deck |
2 deck |
|
Screen length x Screen width |
2,500 x 1,000 mm |
3,000 x 1,200 mm |
3,500 x 1,300 mm |
|
Screen type |
Mesh screen |
Mesh screen |
Mesh screen |
